About this item :
CPU (MAX SUPPORT) : RYZEN
SOCKET : AM4
CHIPSE : T AMD® A320 Chipset
DDR4 MEMORY : 1866/ 2133/ 2400/ 2667Mhz (by JEDEC) 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz (by A-XMP OC MODE)
MEMORY CHANNEL : Dual
DIMM SLOTS : 2
MAX MEMORY (GB) : 64
PCI-E X16 : 1
PCI-E GEN : Gen3
PCI-E X1 : 1
SATAIII : 4
M.2 SLOT : 1
PCI-E X16 :1
PCI-E GEN : Gen3
PCI-E X1 : 1
SATAII : 4
M.2 SLOT : 1
RAID : 0/1/0
TPM (HEADER) : 1
LAN : 1x Realtek® 8111H
SB 3.2 PORTS (FRONT) :2(Gen1, Type A)
USB 3.2 PORTS (REAR) : 4(Gen1, Type A)
USB 2.0 PORTS (FRONT) : 4
USB 2.0 PORTS (REAR) : 2
SERIAL PORTS(FRONT) : 1
AUDIO PORTS (REAR) : Realtek® ALC892/ALC897 Codec
DVI-D 0 : 1
HDMI :1
DIRECTX : 12
FORM FACTOR : m-ATX
OPERATING SYSTEM : Support for Windows® 10 64-bit Support for Windows® 7 64-bit * To support Windows®7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
PROCESSOR : Supports 1st, 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4
CHIPSET : AMD® A320 Chipset
MEMORY:
– 2 x DDR4 memory slots, support up to 64GB *ComboPI 1.0.0.3-based and above BIOS are required.
– Support DDR4 1866/ 2133/ 2400/ 2667/ 2933(OC)/ 3200(OC)Mhz(by JEDEC)
– Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz (by A-XMP OC MODE)
– Dual channel memory architecture – Supports ECC UDIMM memory (non-ECC mode)
– Support non-ECC UDIMM memory
SLOTS : 1 x PCIe 3.0 x16 slot
– Supports x16 speed 1st, 2nd and 3rd Gen AMD Ryzen™
