| Year Introduced | 2016 |
|
| Megapixels | 20.2 |
|
| Total Pixels | 21.5 |
|
| Sensor Size | 36.0 x 24.0mm |
|
| Pixel Dimensions | 5472 x 3648 |
|
| Pixel Size | 6.58µm |
|
| Diffraction-Limited Aperture | f/10.6 |
|
| Sensor Stabilization | N |
|
| Lens Mount | EF (excludes EF-S lenses), TS-E, MP-E |
|
| FOVCF | 1.0x |
|
| Image Processor | Dual DIGIC 6+ |
|
| |
| Type | TTL secondary image-forming phase-difference detection system with AF-dedicated CMOS sensor |
|
| Points | 61 points (Cross-type AF points: Max. 41 points) |
|
| Working Range | EV -3 - 18 (at 23°C & ISO100) |
|
| Modes | One Shot
AI Servo AF (AI Servo AF III+) |
|
| Point Selection | Automatic selection: All 61 point AF (based on EOS iTR AF setting)
Manual selection: Single point AF (selectable points 61, 15, 9 or cross type only points selectable)
Manual selection: Sngle point Spot AF
Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding 8 points
Manual selection: Zone AF (all AF points divided into 9 focusing zones)
Manual selection: Large Zone AF (all AF points divided into 3 focusing zones)
AF points can be selected separately for vertical and horizontal shooting |
|
| Microadjustment | Manual: Enter adjustment +/- 20 steps (wide and tele setting for zoom lenses)
Adjust all lenses by same amount
Adjust up to 40 lenses individually
Adjustments remembered for lens by serial number |
|
| |
| Metering Modes | Approx. 360,000-pixel RGB+IR metering sensor, 216-zone metering. EOS Intelligent Subject Analysis system
(1) Evaluative metering (linked to All AF point)
(2) Partial metering (approx. 6.2% of viewfinder at centre)
(3) Spot metering:
Center spot metering (approx. 1.5% viewfinder at centre)
AF point-linked spot metering
Multi-spot metering
(4) Centre weighted average metering |
|
| Metering Range | EV 0 – 20 (at 73°F/23°C, ISO 100, with evaluative metering) |
|
| Exposure Comp | ±5 stops in 1/3- or 1/2-stop increments |
|
| AEB | ±3 stops in 1/3- or 1/2-stop increments |
|
| ISO Sensitivity | Auto (100-51200), 100-51200 (in 1/3-stop or whole stop increments)
ISO can be expanded to L: 50, H1 102400, H2 204800, H3 409600 |
|
| Shutter Speed | 30 - 1/8000 sec (1/2 or 1/3 stop increments) + Bulb (Shutter speed range available varies according to shooting mode) |
|
| WB Settings | AWB (Ambience priority/White priority), Daylight, Shade, Cloudy,Tungsten
Fluorescent Light, Flash, Custom, Color Temperature, and Personal (1-5)
1. Blue/Amber +/-9
2. Magenta/ Green +/-9. |
|
| Custom WB | Yes, 5 setting can be registered |
|
| |
| Type | Pentaprism |
|
| Coverage | Approx. 100% |
|
| Magnification | Approx. 0.76x |
|
| Eyepoint | Approx. 20mm |
|
| Information | AF information: Single/Spot AF points, AF Frame, AF status, Focus indicator, AF mode, AF point selection, AF point registration
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, flash metering, spot metering circle, exposure warning, AEB, metering mode, shooting mode
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light.
Image information: Card information, maximum burst (2 digit display), Highlight tone priority (D+).
Composition information: Grid, Electronic level
Other information: Battery check, Warning symbol, Flicker Detection, drive mode, white balance, JPEG/RAW indicator |
|
| DOF Preview | Yes, with Depth of Field preview button. |
|
| Eyepiece Shutter | Built in |
|
| |
| Type | 3.2" (8.11cm) Clear View LCD II, approx. 1620K dots |
|
| Coating | Anti-reflection and Anti-smudge. Reinforced glass incorporated |
|
| Brightness Adj | Adjustable to one of seven levels |
|
| Display Options | (1) Quick Control Screen
(2) Camera settings
(3) Dual Axis Electronic Level
(4) Custom Quick Control Screen |
|
| |
| Built-in GN | N/A (ISO 100, meters) |
|
| Built-in Coverage | N/A |
|
| Built-in Recycle Time | N/A |
|
| Modes | E-TTL II Auto Flash, Metered Manual |
|
| X-Sync | 1/250sec |
|
| Exposure Compensation | ±3 stops in 1/3- or 1/2-stop increments |
|
| Hot Shoe/PC Terminal | Yes / Yes |
|
| External Flash Comp | E-TTL II with EX series Speedlites, wireless multi-flash support |
|
| External Flash Control | Via camera menu |
|
| |
| Shooting Modes | Program AE , Shutter priority AE, Aperture priority AE, Manual (Stills and Movie), Bulb, Custom (x3) |
|
| Picture Styles | Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3) |
|
| Image Processing | Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Lens optical correction (Not possible with M-RAW and S-RAW):
- Peripheral illumination correction
- Chromatic aberration correction
- Distortion correction (during or after still photo shooting)
- Diffraction correction (during or after still photo shooting)
- Digital Lens Optimizer (after still photo shooting)
Resize to M1, M2 or S (frame grab images from 4K movies and images shot in S quality cannot be resized)
Cropping: JPEG images can be cropped (Aspect ratio is fixed - 3:2 or 2:3)
- 41 cropping sizes selectable, from 13% to 95% (diagonal)
- Switch between vertical and horizontal cropping orientation
- Cropping frame can be moved using touch screen operation
RAW image processing - during image Playback only
Multiple exposure
4K Frame Grab |
|
| Drive Modes | Single, Continuous High, Continuous Low, Silent single, Silent Continous High, Silent Continuous Low, Self timer (2s+remote, 10s+remote) |
|
| Continuous Shooting | Max. Approx. 14fps. with full AF / AE tracking, speed maintained for up to unlimited number of JPEGs or 170 RAW images, with CFast 2.0 card
Max. 16fps in Live View mode with mirror locked up and exposure and AF locked on first frame |
|
| Shutter Lag | 36-55ms |
|
| Viewfinder Blackout | N/A |
|
| |
| FrameRate | 29.97 fps |
|
| Focusing | Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Dual Pixel CMOS AF (Face Detection and Tracking AF, FlexiZone - Single), available with all EF lenses |
|
| Metering | Real-time evaluative metering with image sensor (315-zone)
Partial metering (approx. 6.5% of Live View screen)
Spot metering (approx. 2.8% of Live View screen)
Center-weighted average metering
Active metering timer can be changed |
|
| Display Options | 3 levels available through INFO. button: No information, Basic shooting information, Histogram
Multiple Exposure status also available in Multiple Exposure mode |
|
| |
| Still ImageType | JPEG: 10 compression options
RAW: RAW, M-RAW, S-RAW (14bit, Canon original RAW 2nd edition)
Complies with Exif 2.30 and Design rule for Camera File system 2.0
Complies with Digital Print Order Format [DPOF] Version 1.1 |
|
| Image Size | JPEG: (L) 5472x3648, (M1) 4368x2912, (M2) 3648x2432, (S) 2736x1824
RAW: (RAW) 5472x3648, (M-RAW) 4104x2736, (S-RAW) 2736x1824 |
|
| Movie Type | MOV Video: 4K - Motion JPEG (internal recording only), Full HD - MPEG4 AVC / H.264 variable (average) bit rate, Audio: Linear PCM
MP4 Video: Full HD - MPEG4 AVC/H.264, Audio: AAC |
|
| Movie Size | 4K (17:9) - 4096 x 2160
Full HD (16:9) - 1920 x 1080 |
|
| Movie Length | Max duration 29min 59sec. (excluding High Frame Rate movies). No 4GB file limit with exFAT CF or CFast card |
|
| |
| Wireless Features |
|
|
| GPS | Built-in |
|
| Custom Functions | 34 Custom Functions |
|
| LCD Panel / Illumination | Yes / Yes |
|
| Water & Dust Resistance | Yes |
|
| Sound Memo | Up to 30sec per image - 48Khz or 8Khz |
|
| |
| Computer Interface | SuperSpeed USB (USB 3.0) |
|
| Other Interface | HDMI mini out (Type C, HDMI-CEC compatible), System Extension Terminal (for WFT-E8 and WFT-E6), External Microphone In / Line In (Stereo mini jack), Headphone socket (Stereo mini jack), RJ-45 (gigabit ethernet), N3-type remote control terminal |
|
| |
| Memory Type | CF Card (Type I; compatible with UDMA 7 CF cards) and CFast Card (CFast 2.0 supported) |
|
| |
| Battery | Rechargeable Li-ion Battery LP-E19 (or LP-E4N, LP-E4) |
|
| Battery Life | Approx. 1210 (at 23°C, AE 50%, FE 50%)
1020 (at 0°C, AE 50%, FE 50%) |
|
| Power Supply Battery Chargers | Battery charger LC-E19 (supplied), AC Adapter AC-E19, DC Coupler DC-E19, AC Adapter kit ACK-E4 |
|
| |
| Body Materials | Magnesium Alloy body covers |
|
| Shutter Durability Rating | 400,000 |
|
| Operating Environment | 0 – 45 °C, 85% or less humidity |
|
| Dimensions Inches | 6.22 x 6.6 x 3.25" (158.0 x 167.6 x 82.6mm) |
|
| CIPA Weight | 53.97 oz (1530g) |
|
| |
| Viewfinder | Eyecup Eg, Eg-series Dioptric Adjustment Lens with Rubber Frame Eg, Anti Fog Eyepiece Eg, Angle Finder C |
|
| Wireless File Transmitter | Wireless File Transmitter WFT-E6A, WFT-E8A |
|
| Compatible Lenses | All EF lenses (excludes EF-S lenses), TS-E and MP-E lenses |
|
| Battery Grip | N/A |
|
| Remote | Remote control with N3 type contact, Wireless Controller LC-5 and Speedlite 600EX-RT |
